在當前要求日益嚴格的背景下，廢氣處理技術也在不斷升級。其中，沸石轉輪裝置+RTO 蓄熱式焚燒爐是一種較為且有效的廢氣處理技術，被廣泛應用于噴涂、包裝印刷等行業。本文將詳細介紹沸石轉輪裝置+RTO 蓄熱式焚燒爐的工作原理。

Against the backdrop of increasingly strict environmental requirements, exhaust gas treatment technology is also constantly upgrading. Among them, the zeolite rotary device+RTO thermal storage incinerator is a relatively advanced and effective waste gas treatment technology, widely used in industries such as spraying, packaging and printing. This article will provide a detailed introduction to the working principle of the zeolite rotary device+RTO thermal storage incinerator.

沸石轉輪裝置是一種以沸石為吸附劑的廢氣處理設備，它利用沸石對廢氣中的有害物質進行吸附，從而達到凈化廢氣的目的。沸石轉輪裝置由吸附區、脫附區和冷卻區三個部分組成。在吸附區，廢氣通過吸附風機的作用，經過過濾箱過濾掉大顆粒物質后，進入沸石轉輪進行吸附；在脫附區，廢氣在高溫空氣的作用下，被沸石轉輪上的吸附劑脫附出來，形成高濃度廢氣；在冷卻區，經過脫附的廢氣被冷卻后，可以直接排放。

The zeolite rotary device is a waste gas treatment equipment that uses zeolite as an adsorbent. It uses zeolite to adsorb harmful substances in the waste gas, thereby achieving the goal of purifying the waste gas. The zeolite rotary device consists of three parts: adsorption zone, desorption zone, and cooling zone. In the adsorption zone, the exhaust gas is filtered out of large particles through the action of the adsorption fan, and then enters the zeolite wheel for adsorption; In the desorption zone, the exhaust gas is desorbed by the adsorbent on the zeolite wheel under the action of high-temperature air, forming high concentration exhaust gas; In the cooling zone, the desorbed exhaust gas can be directly discharged after being cooled.

RTO 蓄熱式焚燒爐則是利用蓄熱材料對廢氣進行焚燒處理的一種設備。它主要由燃燒室、蓄熱室和提升閥組成。在燃燒室中，經過沸石轉輪處理后的廢氣在高溫下燃燒，生成的高溫氣體通過蓄熱室時，將蓄熱材料中的熱量釋放出來，使廢氣得到充分焚燒。提升閥的作用是在廢氣處理過程中，不斷地將蓄熱室中的高溫氣體排出，以保證焚燒過程的順利進行。

RTO thermal storage incinerator is a device that uses thermal storage materials to incinerate waste gas. It mainly consists of a combustion chamber, a heat storage chamber, and a lifting valve. In the combustion chamber, the waste gas treated by the zeolite wheel burns at high temperatures. When the generated high-temperature gas passes through the heat storage chamber, it releases the heat from the heat storage material, allowing the waste gas to be fully incinerated. The function of the lifting valve is to continuously discharge the high-temperature gas in the heat storage chamber during the waste gas treatment process, to ensure the smooth progress of the incineration process.

沸石轉輪裝置與 RTO 蓄熱式焚燒爐的結合，使廢氣處理過程更加。，沸石轉輪裝置對廢氣進行吸附，將廢氣中的有害物質濃縮，從而降低了后續焚燒處理的壓力；其次，RTO 蓄熱式焚燒爐對廢氣進行焚燒，使有害物質得到徹底分解，確保了廢氣處理的效果。同時，兩者的結合還實現了能源的循環利用，降低了運行成本。

The combination of zeolite rotary device and RTO thermal storage incinerator makes the waste gas treatment process more efficient. Firstly, the zeolite rotary device adsorbs the waste gas, concentrating harmful substances in the waste gas, thereby reducing the pressure of subsequent incineration treatment; Secondly, the RTO thermal storage incinerator incinerates waste gas, thoroughly decomposing harmful substances and ensuring the effectiveness of waste gas treatment. At the same time, the combination of the two also achieves energy recycling and reduces operating costs.

總之，沸石轉輪裝置+RTO 蓄熱式焚燒爐的工作原理是利用沸石轉輪對廢氣進行吸附濃縮，再通過 RTO 蓄熱式焚燒爐進行焚燒處理，從而實現廢氣的有效凈化。這一技術具有處理效果好、能耗低、運行穩定等優點，為我國廢氣處理行業的發展提供了有力支持。

In summary, the working principle of the zeolite wheel device+RTO thermal storage incinerator is to use the zeolite wheel to adsorb and concentrate the waste gas, and then incinerate it through the RTO thermal storage incinerator, thereby achieving effective purification of the waste gas. This technology has the advantages of good treatment effect, low energy consumption, and stable operation, providing strong support for the development of China's waste gas treatment industry.
